Timken 12168 - 12303 bearing

All our Timken 12168 - 12303 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 12168 - 12303

Series

12000

Cone Part Number

12168

Cup Part Number

12303

Design Units

Imperial

Bearing Weight

0.7000 lb
0.3000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.0312 in
76.992 mm

d - Cone Bore

1.6875 in
42.863 mm

B - Cone Width

0.6750 in
17.145 mm

C - Cup Width

0.4688 in
11.908 mm

T - Bearing Width

0.6875 in
17.463 mm

Z - Number of Rollers Per Row

20

R - Cone Backface "To Clear" Radius¹

0.060 in
1.520 mm

r - Cup Backface "To Clear" Radius²

0.060 in
1.52 mm

da - Cone Frontface Backing Diameter

1.91 in
48.51 mm

db - Cone Backface Backing Diameter

2.01 in
51.05 mm

Da - Cup Frontface Backing Diameter

2.91 in
73.90 mm

Db - Cup Backface Backing Diameter

2.68 in
68.07 mm

Ab - Cage-Cone Frontface Clearance

0.09 in
2.29 mm

Aa - Cage-Cone Backface Clearance

0.06 in
1.52 mm

a - Effective Center Location³

0.00 in
0.00 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

2890 lbf
12800 N

C1 - Dynamic Radial Rating (1 million revolutions)²

11100 lbf
49500 N

C0 - Static Radial Rating

13100 lbf
58100 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

2500 lbf
11100 N

K - Factor¹

1.15

e - ISO Factor²

0.51

Y - ISO Factor³

1.19

G1 - Heat Generation Factor (Roller-Raceway)

21

G2 - Heat Generation Factor (Rib-Roller End)

15.8

Cg - Geometry Factor

0.0766

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 12168 - 12303 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 12168 - 12303 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Tapered Roller 12168 - 12303 Bearings_TS specifications Timken dimensions -Tancbearing

12168 - 12303 bearing
12168 - 12303 bearing
12168 - 12303 bearing
12168 - 12303 bearing
12168 - 12303 bearing
12168 - 12303 bearing
12168 - 12303 bearing
12168 - 12303 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

B:

17.145mm

Model:

12168/12303

D:

76.992mm

C0r:

58100N

Brand:

TIMKENBearing

d:

42.862mm

Cr:

45900N

m:

0.32kg

Category:

TaperedRollerBearings

D:

76.992mm

B:

17.145mm

OilRPM:

66001/min

Brand:

KOYOBearing

d:

42.862mm

m:

0.317kg

Cr:

48.4N

C0r:

62.2N

Model:

12168/12303

Category:

TaperedRollerBearings

GreaseRPM:

50001/min
