Timken 16986 - 16929 bearing

All our Timken 16986 - 16929 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 16986 - 16929

Series 16900
Cone Part Number 16986
Cup Part Number 16929
Design Units Imperial
Bearing Weight 0.8000 lb
0.4000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 2.9523 in
74.988 mm
d - Cone Bore 1.6924 in
42.987 mm
B - Cone Width 0.7810 in
19.837 mm
C - Cup Width 0.5625 in
14.288 mm
T - Bearing Width 0.7625 in
19.368 mm
Z - Number of Rollers Per Row 20
R - Cone Backface "To Clear" Radius1 0.060 in
1.520 mm
r - Cup Backface "To Clear" Radius2 0.050 in
1.27 mm
da - Cone Frontface Backing Diameter 1.91 in
48.51 mm
db - Cone Backface Backing Diameter 2.01 in
51.05 mm
Da - Cup Frontface Backing Diameter 2.83 in
71.88 mm
Db - Cup Backface Backing Diameter 2.68 in
68.07 mm
Ab - Cage-Cone Frontface Clearance 0 in
0.00 mm
Aa - Cage-Cone Backface Clearance 0.00 in
0.00 mm
a - Effective Center Location3 -0.08 in
-2.00 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 3470 lbf
15400 N
C1 - Dynamic Radial Rating (1 million revolutions)2 13400 lbf
59500 N
C0 - Static Radial Rating 16500 lbf
73500 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 2640 lbf
11700 N
K - Factor1 1.31
e - ISO Factor2 0.44
Y - ISO Factor3 1.35
G1 - Heat Generation Factor (Roller-Raceway) 25.1
G2 - Heat Generation Factor (Rib-Roller End) 17.4
Cg - Geometry Factor 0.0783


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 16986 - 16929 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 16986 - 16929 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



price dimensions Timken Tapered Roller 16986 - 16929 Bearings_TS -Tancbearing

  • bearing 16986 - 16929 bearing
  • bearing 16986 - 16929 bearing
  • bearing 16986 - 16929 bearing
  • bearing 16986 - 16929 bearing
  • bearing 16986 - 16929 bearing
  • bearing 16986 - 16929 bearing
  • bearing 16986 - 16929 bearing
  • bearing 16986 - 16929 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 B:
19.837mm
m:
0.36kg
Cr:
55100N
Brand:
TIMKENBearing
D:
74.988mm
Category:
TaperedRollerBearings
d:
42.987mm
C0r:
73500N
Model:
16986/16929
