Timken 22780 - 22720 bearing

All our Timken 22780 - 22720 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 22780 - 22720

Series

22700

Cone Part Number

22780

Cup Part Number

22720

Design Units

Imperial

Bearing Weight

1.3000 lb
0.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.2500 in
82.550 mm

d - Cone Bore

1.6875 in
42.863 mm

B - Cone Width

1.0625 in
26.988 mm

C - Cup Width

0.8125 in
20.638 mm

T - Bearing Width

1.0313 in
26.195 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

1.97 in
50.04 mm

db - Cone Backface Backing Diameter

2.20 in
55.88 mm

Da - Cup Frontface Backing Diameter

3.05 in
77.00 mm

Db - Cup Backface Backing Diameter

2.80 in
71.12 mm

Ab - Cage-Cone Frontface Clearance

0.04 in
1.02 mm

Aa - Cage-Cone Backface Clearance

0.07 in
1.78 mm

a - Effective Center Location³

-0.25 in
-6.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5420 lbf
24100 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20900 lbf
92900 N

C0 - Static Radial Rating

25800 lbf
115000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

3730 lbf
16600 N

K - Factor¹

1.45

e - ISO Factor²

0.4

Y - ISO Factor³

1.49

G1 - Heat Generation Factor (Roller-Raceway)

33.9

G2 - Heat Generation Factor (Rib-Roller End)

15.3

Cg - Geometry Factor

0.0841

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 22780 - 22720 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 22780 - 22720 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

SPEC Tapered Roller 22780 - 22720 Bearings_TS price Timken -Tancbearing

22780 - 22720 bearing
22780 - 22720 bearing
22780 - 22720 bearing
22780 - 22720 bearing
22780 - 22720 bearing
22780 - 22720 bearing
22780 - 22720 bearing
22780 - 22720 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

m:

0.6kg

d:

42.862mm

Model:

22780/22720

Brand:

TIMKENBearing

C0r:

115000N

B:

26.988mm

D:

82.550mm

Category:

TaperedRollerBearings

Cr:

86000N

NewModel:

4T-22780/22720

B:

26.988mm

Cr:

75.5N

Category:

TaperedRollerBearings

d:

42.862mm

Model:

4T-22780/22720

D:

82.55mm

m:

0.617kg

C0r:

97N

GreaseRPM:

46001/min

Brand:

NTNBearing

OilRPM:

61001/min
