Timken 25576 - 25521 bearing

All our Timken 25576 - 25521 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 25576 - 25521

Series

25500

Cone Part Number

25576

Cup Part Number

25521

Design Units

Imperial

Bearing Weight

1.3000 lb
0.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.2700 in
83.058 mm

d - Cone Bore

1.6875 in
42.863 mm

B - Cone Width

1.0000 in
25.400 mm

C - Cup Width

0.7500 in
19.050 mm

T - Bearing Width

0.9375 in
23.813 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

1.93 in
49.02 mm

db - Cone Backface Backing Diameter

2.17 in
55.12 mm

Da - Cup Frontface Backing Diameter

3.05 in
77.00 mm

Db - Cup Backface Backing Diameter

2.83 in
71.88 mm

Ab - Cage-Cone Frontface Clearance

0.03 in
0.76 mm

Aa - Cage-Cone Backface Clearance

0.04 in
1.02 mm

a - Effective Center Location³

-0.25 in
-6.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5270 lbf
23500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20300 lbf
90500 N

C0 - Static Radial Rating

24900 lbf
111000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

3020 lbf
13500 N

K - Factor¹

1.74

e - ISO Factor²

0.33

Y - ISO Factor³

1.79

G1 - Heat Generation Factor (Roller-Raceway)

35.2

G2 - Heat Generation Factor (Rib-Roller End)

14.3

Cg - Geometry Factor

0.0801

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 25576 - 25521 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 25576 - 25521 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Timken price dimensions Tapered Roller 25576 - 25521 Bearings_TS -Tancbearing

25576 - 25521 bearing
25576 - 25521 bearing
25576 - 25521 bearing
25576 - 25521 bearing
25576 - 25521 bearing
25576 - 25521 bearing
25576 - 25521 bearing
25576 - 25521 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

C0r:

111000N

Brand:

TIMKENBearing

m:

0.57kg

D:

83.058mm

Cr:

83800N

Category:

TaperedRollerBearings

Model:

25576/25521

d:

42.862mm

B:

25.400mm

d:

42.862mm

D:

83.058mm

C0r:

111000N

m:

0.6kg

Brand:

TIMKENBearing

B:

25.400mm

Category:

TaperedRollerBearings

Model:

25576/25521-B

Cr:

83800N
