Timken 25577 - 25518 bearing

All our Timken 25577 - 25518 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 25577 - 25518

Series

25500

Cone Part Number

25577

Cup Part Number

25518

Design Units

Imperial

Bearing Weight

1.2000 lb
0.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.2273 in
81.973 mm

d - Cone Bore

1.6880 in
42.875 mm

B - Cone Width

1.0000 in
25.400 mm

C - Cup Width

0.7525 in
19.114 mm

T - Bearing Width

0.9400 in
23.876 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.040 in
1.02 mm

da - Cone Frontface Backing Diameter

1.93 in
49.02 mm

db - Cone Backface Backing Diameter

2.17 in
55.12 mm

Da - Cup Frontface Backing Diameter

3.05 in
77.00 mm

Db - Cup Backface Backing Diameter

2.91 in
73.91 mm

Ab - Cage-Cone Frontface Clearance

0.03 in
0.76 mm

Aa - Cage-Cone Backface Clearance

0.04 in
1.02 mm

a - Effective Center Location³

-0.25 in
-6.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5270 lbf
23500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20300 lbf
90500 N

C0 - Static Radial Rating

24900 lbf
111000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

3020 lbf
13500 N

K - Factor¹

1.74

e - ISO Factor²

0.33

Y - ISO Factor³

1.79

G1 - Heat Generation Factor (Roller-Raceway)

35.2

G2 - Heat Generation Factor (Rib-Roller End)

14.3

Cg - Geometry Factor

0.0801

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 25577 - 25518 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 25577 - 25518 Bearings, welcome to your calling.
