Timken 25577 - 25520 bearing

All our Timken 25577 - 25520 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 25577 - 25520

Series 25500
Cone Part Number 25577
Cup Part Number 25520
Design Units Imperial
Bearing Weight 1.3000 lb
0.6000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 3.2650 in
82.931 mm
d - Cone Bore 1.6880 in
42.875 mm
B - Cone Width 1.0000 in
25.400 mm
C - Cup Width 0.7500 in
19.050 mm
T - Bearing Width 0.9375 in
23.813 mm
Z - Number of Rollers Per Row 18
R - Cone Backface "To Clear" Radius1 0.140 in
3.560 mm
r - Cup Backface "To Clear" Radius2 0.030 in
0.76 mm
da - Cone Frontface Backing Diameter 1.93 in
49.02 mm
db - Cone Backface Backing Diameter 2.17 in
55.12 mm
Da - Cup Frontface Backing Diameter 3.05 in
77.00 mm
Db - Cup Backface Backing Diameter 2.91 in
73.91 mm
Ab - Cage-Cone Frontface Clearance 0.03 in
0.76 mm
Aa - Cage-Cone Backface Clearance 0.04 in
1.02 mm
a - Effective Center Location3 -0.25 in
-6.40 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 5270 lbf
23500 N
C1 - Dynamic Radial Rating (1 million revolutions)2 20300 lbf
90500 N
C0 - Static Radial Rating 24900 lbf
111000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 3020 lbf
13500 N
K - Factor1 1.74
e - ISO Factor2 0.33
Y - ISO Factor3 1.79
G1 - Heat Generation Factor (Roller-Raceway) 35.2
G2 - Heat Generation Factor (Rib-Roller End) 14.3
Cg - Geometry Factor 0.0801


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 25577 - 25520 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 25577 - 25520 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



specifications Timken Tapered Roller 25577 - 25520 Bearings_TS SPEC -Tancbearing
