Timken 25577C - 25523 bearing

All our Timken 25577C - 25523 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 25577C - 25523

Series

25500

Cone Part Number

25577C

Cup Part Number

25523

Design Units

Imperial

Bearing Weight

1.4000 lb
0.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.2650 in
82.931 mm

d - Cone Bore

1.6880 in
42.875 mm

B - Cone Width

1.0000 in
25.400 mm

C - Cup Width

0.8750 in
22.225 mm

T - Bearing Width

1.0625 in
26.988 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.090 in
2.29 mm

da - Cone Frontface Backing Diameter

2.01 in
51.05 mm

db - Cone Backface Backing Diameter

2.24 in
56.90 mm

Da - Cup Frontface Backing Diameter

3.05 in
77.00 mm

Db - Cup Backface Backing Diameter

2.83 in
71.88 mm

Ab - Cage-Cone Frontface Clearance

0 in
0.00 mm

Aa - Cage-Cone Backface Clearance

0.00 in
0.00 mm

a - Effective Center Location³

-0.25 in
-6.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

4880 lbf
21700 N

C1 - Dynamic Radial Rating (1 million revolutions)²

18800 lbf
83800 N

C0 - Static Radial Rating

24900 lbf
111000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

2800 lbf
12500 N

K - Factor¹

1.74

e - ISO Factor²

0.33

Y - ISO Factor³

1.79

G1 - Heat Generation Factor (Roller-Raceway)

35.2

G2 - Heat Generation Factor (Rib-Roller End)

14.3

Cg - Geometry Factor

0.0801

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 25577C - 25523 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 25577C - 25523 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Tapered Roller 25577C - 25523 Bearings_TS price Timken dimensions -Tancbearing

25577C - 25523 bearing
25577C - 25523 bearing
25577C - 25523 bearing
25577C - 25523 bearing
25577C - 25523 bearing
25577C - 25523 bearing
25577C - 25523 bearing
25577C - 25523 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Model:

25577/25520

D:

82.931mm

B:

25.4mm

d:

42.875mm

Brand:

KOYOBearing

C0r:

100N

m:

0.582kg

GreaseRPM:

48001/min

Category:

TaperedRollerBearings

OilRPM:

63001/min

Cr:

77.2N

OilRPM:

60001/min

D:

82.931mm

B:

25.4mm

C0r:

98000N

Brand:

NACHIBearing

d:

42.875mm

Model:

25577/25523

GreaseRPM:

45001/min

Category:

TaperedRollerBearings

m:

0.625kg

Cr:

78500N

m:

0.63kg

GreaseRPM:

40001/min

Model:

H-25577/H-25523

Cr:

77300N

D:

82.931mm

Brand:

NACHIBearing

Category:

TaperedRollerBearings

B:

25.4mm

C0r:

100000N

OilRPM:

55001/min

d:

42.875mm

d:

42.875mm

OilRPM:

60001/min

D:

83.058mm

Model:

25577/25521

GreaseRPM:

45001/min

C0r:

98000N

m:

0.579kg

Brand:

NACHIBearing

Cr:

78500N

Category:

TaperedRollerBearings

B:

25.4mm

d:

42.875mm

m:

0.57kg

B:

25.400mm

D:

82.550mm

C0r:

111000N

Brand:

TIMKENBearing

Model:

25577/25519

Cr:

83800N

Category:

TaperedRollerBearings

Category:

TaperedRollerBearings

Model:

25577/25518

Brand:

TIMKENBearing

d:

42.875mm

m:

0.56kg

C0r:

111000N

D:

81.973mm

Cr:

83800N

B:

25.400mm
