Timken 25578 - 25522 bearing

All our Timken 25578 - 25522 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 25578 - 25522

Series

25500

Cone Part Number

25578

Cup Part Number

25522

Design Units

Imperial

Bearing Weight

1.3000 lb
0.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.2700 in
83.058 mm

d - Cone Bore

1.6875 in
42.863 mm

B - Cone Width

1.0000 in
25.400 mm

C - Cup Width

0.7525 in
19.114 mm

T - Bearing Width

0.9400 in
23.876 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.090 in
2.290 mm

r - Cup Backface "To Clear" Radius²

0.080 in
2.03 mm

da - Cone Frontface Backing Diameter

1.95 in
49.53 mm

db - Cone Backface Backing Diameter

2.09 in
53.09 mm

Da - Cup Frontface Backing Diameter

3.05 in
77.00 mm

Db - Cup Backface Backing Diameter

2.87 in
72.90 mm

Ab - Cage-Cone Frontface Clearance

0.03 in
0.76 mm

Aa - Cage-Cone Backface Clearance

0.04 in
1.02 mm

a - Effective Center Location³

-0.25 in
-6.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5270 lbf
23500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20300 lbf
90500 N

C0 - Static Radial Rating

24900 lbf
111000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

3020 lbf
13500 N

K - Factor¹

1.74

e - ISO Factor²

0.33

Y - ISO Factor³

1.79

G1 - Heat Generation Factor (Roller-Raceway)

35.2

G2 - Heat Generation Factor (Rib-Roller End)

14.3

Cg - Geometry Factor

0.0801

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 25578 - 25522 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 25578 - 25522 Bearings, welcome to your calling.
