Timken 26884 - 26822 bearing

All our Timken 26884 - 26822 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 26884 - 26822

Series 26800
Cone Part Number 26884
Cup Part Number 26822
Design Units Imperial
Bearing Weight 1.1000 lb
0.5000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 3.1250 in
79.375 mm
d - Cone Bore 1.6880 in
42.875 mm
B - Cone Width 1.0000 in
25.400 mm
C - Cup Width 0.7500 in
19.050 mm
T - Bearing Width 0.9375 in
23.813 mm
Z - Number of Rollers Per Row 18
R - Cone Backface "To Clear" Radius1 0.140 in
3.560 mm
r - Cup Backface "To Clear" Radius2 0.030 in
0.76 mm
da - Cone Frontface Backing Diameter 1.91 in
48.51 mm
db - Cone Backface Backing Diameter 2.17 in
55.12 mm
Da - Cup Frontface Backing Diameter 2.94 in
74.68 mm
Db - Cup Backface Backing Diameter 2.80 in
71.12 mm
Ab - Cage-Cone Frontface Clearance 0.05 in
1.27 mm
Aa - Cage-Cone Backface Clearance 0.06 in
1.52 mm
a - Effective Center Location3 -0.29 in
-7.40 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 5310 lbf
23600 N
C1 - Dynamic Radial Rating (1 million revolutions)2 20500 lbf
91100 N
C0 - Static Radial Rating 24800 lbf
110000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 2900 lbf
12900 N
K - Factor1 1.83
e - ISO Factor2 0.32
Y - ISO Factor3 1.88
G1 - Heat Generation Factor (Roller-Raceway) 32.8
G2 - Heat Generation Factor (Rib-Roller End) 13.3
Cg - Geometry Factor 0.077


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 26884 - 26822 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 26884 - 26822 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



price Tapered Roller 26884 - 26822 Bearings_TS sale Timken -Tancbearing
