Timken 26884 - 26824 bearing

All our Timken 26884 - 26824 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 26884 - 26824

Series

26800

Cone Part Number

26884

Cup Part Number

26824

Design Units

Imperial

Bearing Weight

1.1000 lb
0.5000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.1496 in
80.000 mm

d - Cone Bore

1.6880 in
42.875 mm

B - Cone Width

1.0000 in
25.400 mm

C - Cup Width

0.7500 in
19.050 mm

T - Bearing Width

0.9375 in
23.813 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.050 in
1.27 mm

da - Cone Frontface Backing Diameter

1.91 in
48.51 mm

db - Cone Backface Backing Diameter

2.17 in
55.12 mm

Da - Cup Frontface Backing Diameter

2.94 in
74.68 mm

Db - Cup Backface Backing Diameter

2.76 in
70.10 mm

Ab - Cage-Cone Frontface Clearance

0.05 in
1.27 mm

Aa - Cage-Cone Backface Clearance

0.06 in
1.52 mm

a - Effective Center Location³

-0.29 in
-7.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5310 lbf
23600 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20500 lbf
91100 N

C0 - Static Radial Rating

24800 lbf
110000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

2900 lbf
12900 N

K - Factor¹

1.83

e - ISO Factor²

0.32

Y - ISO Factor³

1.88

G1 - Heat Generation Factor (Roller-Raceway)

32.8

G2 - Heat Generation Factor (Rib-Roller End)

13.3

Cg - Geometry Factor

0.077

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 26884 - 26824 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 26884 - 26824 Bearings, welcome to your calling.
