Timken 26886 - 26820 bearing

All our Timken 26886 - 26820 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 26886 - 26820

Series

26800

Cone Part Number

26886

Cup Part Number

26820

Design Units

Imperial

Bearing Weight

1.2000 lb
0.5000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.1562 in
80.167 mm

d - Cone Bore

1.6880 in
42.875 mm

B - Cone Width

1.0000 in
25.400 mm

C - Cup Width

0.8125 in
20.638 mm

T - Bearing Width

1.0000 in
25.400 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.060 in
1.520 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

1.91 in
48.51 mm

db - Cone Backface Backing Diameter

2.01 in
51.05 mm

Da - Cup Frontface Backing Diameter

2.94 in
74.68 mm

Db - Cup Backface Backing Diameter

2.72 in
69.09 mm

Ab - Cage-Cone Frontface Clearance

0.05 in
1.27 mm

Aa - Cage-Cone Backface Clearance

0.06 in
1.52 mm

a - Effective Center Location³

-0.29 in
-7.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5310 lbf
23600 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20500 lbf
91100 N

C0 - Static Radial Rating

24800 lbf
110000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

2900 lbf
12900 N

K - Factor¹

1.83

e - ISO Factor²

0.32

Y - ISO Factor³

1.88

G1 - Heat Generation Factor (Roller-Raceway)

32.8

G2 - Heat Generation Factor (Rib-Roller End)

13.3

Cg - Geometry Factor

0.077

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 26886 - 26820 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 26886 - 26820 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Timken Tapered Roller 26886 - 26820 Bearings_TS SPEC specifications -Tancbearing

26886 - 26820 bearing
26886 - 26820 bearing
26886 - 26820 bearing
26886 - 26820 bearing
26886 - 26820 bearing
26886 - 26820 bearing
26886 - 26820 bearing
26886 - 26820 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

D:

80.167mm

Brand:

TIMKENBearing

C0r:

110000N

Cr:

84300N

m:

0.54kg

Category:

TaperedRollerBearings

Model:

26886/26830

d:

42.875mm

B:

25.400mm

d:

42.875mm

m:

0.54kg

Brand:

TIMKENBearing

D:

80.167mm

B:

25.400mm

C0r:

110000N

Cr:

84300N

Category:

TaperedRollerBearings

Model:

26886/26820

Recommended models

25577 - 25522 25578 - 25523 59162 - 59412 LM501349 - LM501311 LM501349 - LM501310 HM803146 - HM803112 3579 - 3525 3578AA - 3525 25580 - 25526 46162 - 46369 355A - 354A 2975 - 2924 HM803146 - HM803110 17886 - 17830 25580 - 25521 25580 - 25522 25577 - 25519 25580 - 25519 LM300848 - LM300811 461 - 453 M802048 - M802011 25581 - 25520 11165X - 11315 3782 - 3720 22780 - 22720 25582 - 25521 3782 - 3726 3578 - 3526 LM501349 - LM501310A 26886 - 26830

please contact EMAIL :sales@tanchin.hk for any inquiry
