Timken 342-S - 332A bearing

All our Timken 342-S - 332A bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 342-S - 332A

Series

335

Cone Part Number

342-S

Cup Part Number

332A

Design Units

Imperial

Bearing Weight

1.0000 lb
0.5000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.1496 in
80.000 mm

d - Cone Bore

1.6880 in
42.875 mm

B - Cone Width

0.8820 in
22.403 mm

C - Cup Width

0.8268 in
21.001 mm

T - Bearing Width

0.9518 in
24.176 mm

Z - Number of Rollers Per Row

15

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.090 in
2.29 mm

da - Cone Frontface Backing Diameter

1.87 in
47.50 mm

db - Cone Backface Backing Diameter

2.13 in
54.10 mm

Da - Cup Frontface Backing Diameter

2.99 in
75.90 mm

Db - Cup Backface Backing Diameter

2.80 in
71.12 mm

Ab - Cage-Cone Frontface Clearance

0.04 in
1.02 mm

Aa - Cage-Cone Backface Clearance

0.03 in
0.76 mm

a - Effective Center Location³

-0.25 in
-6.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5490 lbf
24400 N

C1 - Dynamic Radial Rating (1 million revolutions)²

21200 lbf
94300 N

C0 - Static Radial Rating

18700 lbf
83400 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

2570 lbf
11400 N

K - Factor¹

2.14

e - ISO Factor²

0.27

Y - ISO Factor³

2.2

G1 - Heat Generation Factor (Roller-Raceway)

26.5

G2 - Heat Generation Factor (Rib-Roller End)

13

Cg - Geometry Factor

0.0676

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 342-S - 332A Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 342-S - 332A Bearings, welcome to your calling.
