Timken 3579 - 3525 bearing

All our Timken 3579 - 3525 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 3579 - 3525

Series

3500

Cone Part Number

3579

Cup Part Number

3525

Design Units

Imperial

Bearing Weight

1.7000 lb
0.8000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.4375 in
87.313 mm

d - Cone Bore

1.6875 in
42.863 mm

B - Cone Width

1.2160 in
30.886 mm

C - Cup Width

0.9375 in
23.813 mm

T - Bearing Width

1.1875 in
30.163 mm

Z - Number of Rollers Per Row

16

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

1.95 in
49.53 mm

db - Cone Backface Backing Diameter

2.20 in
55.88 mm

Da - Cup Frontface Backing Diameter

3.23 in
82.00 mm

Db - Cup Backface Backing Diameter

2.95 in
74.93 mm

Ab - Cage-Cone Frontface Clearance

0.03 in
0.76 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.40 in
-10.20 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

6610 lbf
29400 N

C1 - Dynamic Radial Rating (1 million revolutions)²

25500 lbf
113000 N

C0 - Static Radial Rating

30100 lbf
134000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

3460 lbf
15400 N

K - Factor¹

1.91

e - ISO Factor²

0.31

Y - ISO Factor³

1.96

G1 - Heat Generation Factor (Roller-Raceway)

39.5

G2 - Heat Generation Factor (Rib-Roller End)

10.5

Cg - Geometry Factor

0.0808

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 3579 - 3525 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 3579 - 3525 Bearings, welcome to your calling.
