Timken 461 - 454 bearing

All our Timken 461 - 454 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 461 - 454

Series

455

Cone Part Number

461

Cup Part Number

454

Design Units

Imperial

Bearing Weight

3.3000 lb
1.5000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

4.3307 in
110.000 mm

d - Cone Bore

1.6870 in
42.850 mm

B - Cone Width

1.1542 in
29.317 mm

C - Cup Width

1.0630 in
27.000 mm

T - Bearing Width

1.0943 in
27.795 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.030 in
0.760 mm

r - Cup Backface "To Clear" Radius²

0.080 in
2.03 mm

da - Cone Frontface Backing Diameter

2.09 in
53.09 mm

db - Cone Backface Backing Diameter

2.13 in
54.10 mm

Da - Cup Frontface Backing Diameter

3.96 in
100.10 mm

Db - Cup Backface Backing Diameter

3.78 in
96.01 mm

Ab - Cage-Cone Frontface Clearance

0.05 in
1.27 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.28 in
-7.10 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

7900 lbf
35200 N

C1 - Dynamic Radial Rating (1 million revolutions)²

30500 lbf
136000 N

C0 - Static Radial Rating

37200 lbf
166000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

4540 lbf
20200 N

K - Factor¹

1.74

e - ISO Factor²

0.34

Y - ISO Factor³

1.79

G1 - Heat Generation Factor (Roller-Raceway)

58.6

G2 - Heat Generation Factor (Rib-Roller End)

17.1

Cg - Geometry Factor

0.0946

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 461 - 454 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 461 - 454 Bearings, welcome to your calling.
