Timken 46162 - 46368 bearing

All our Timken 46162 - 46368 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 46162 - 46368

Series

46000

Cone Part Number

46162

Cup Part Number

46368

Design Units

Imperial

Bearing Weight

2.4000 lb
1.1000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.6875 in
93.663 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.2500 in
31.750 mm

C - Cup Width

1.0313 in
26.195 mm

T - Bearing Width

1.2500 in
31.750 mm

Z - Number of Rollers Per Row

17

R - Cone Backface "To Clear" Radius¹

0.030 in
0.760 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.01 in
51.05 mm

db - Cone Backface Backing Diameter

2.05 in
52.07 mm

Da - Cup Frontface Backing Diameter

3.46 in
87.88 mm

Db - Cup Backface Backing Diameter

3.11 in
78.99 mm

Ab - Cage-Cone Frontface Clearance

0.04 in
1.02 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.31 in
-7.90 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

7540 lbf
33500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

29100 lbf
129000 N

C0 - Static Radial Rating

35500 lbf
158000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

5190 lbf
23100 N

K - Factor¹

1.45

e - ISO Factor²

0.4

Y - ISO Factor³

1.49

G1 - Heat Generation Factor (Roller-Raceway)

44.4

G2 - Heat Generation Factor (Rib-Roller End)

13.6

Cg - Geometry Factor

0.092

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 46162 - 46368 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 46162 - 46368 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

dimensions Tapered Roller 46162 - 46368 Bearings_TS Timken SPEC -Tancbearing

46162 - 46368 bearing
46162 - 46368 bearing
46162 - 46368 bearing
46162 - 46368 bearing
46162 - 46368 bearing
46162 - 46368 bearing
46162 - 46368 bearing
46162 - 46368 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

C0r:

134N

B:

31.75mm

Model:

46162/46368

D:

93.662mm

Category:

TaperedRollerBearings

m:

1.098kg

OilRPM:

58001/min

Cr:

105N

GreaseRPM:

44001/min

Brand:

KOYOBearing

d:

41.275mm

m:

1.09kg

Category:

TaperedRollerBearings

d:

41.275mm

B:

31.75mm

C0r:

131N

GreaseRPM:

41001/min

D:

93.662mm

NewModel:

4T-46162/46368

Brand:

NTNBearing

OilRPM:

55001/min

Model:

4T-46162/46368

Cr:

104N
