Timken 46162 - 46369 bearing

All our Timken 46162 - 46369 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 46162 - 46369

Series

46000

Cone Part Number

46162

Cup Part Number

46369

Design Units

Imperial

Bearing Weight

2.4000 lb
1.1000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.6875 in
93.663 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.2500 in
31.750 mm

C - Cup Width

1.0313 in
26.195 mm

T - Bearing Width

1.2500 in
31.750 mm

Z - Number of Rollers Per Row

17

R - Cone Backface "To Clear" Radius¹

0.030 in
0.760 mm

r - Cup Backface "To Clear" Radius²

0.050 in
1.27 mm

da - Cone Frontface Backing Diameter

2.01 in
51.05 mm

db - Cone Backface Backing Diameter

2.05 in
52.07 mm

Da - Cup Frontface Backing Diameter

3.46 in
87.88 mm

Db - Cup Backface Backing Diameter

3.19 in
81.03 mm

Ab - Cage-Cone Frontface Clearance

0.04 in
1.02 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.31 in
-7.90 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

7540 lbf
33500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

29100 lbf
129000 N

C0 - Static Radial Rating

35500 lbf
158000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

5190 lbf
23100 N

K - Factor¹

1.45

e - ISO Factor²

0.4

Y - ISO Factor³

1.49

G1 - Heat Generation Factor (Roller-Raceway)

44.4

G2 - Heat Generation Factor (Rib-Roller End)

13.6

Cg - Geometry Factor

0.092

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 46162 - 46369 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 46162 - 46369 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

sale Tapered Roller 46162 - 46369 Bearings_TS dimensions Timken -Tancbearing

46162 - 46369 bearing
46162 - 46369 bearing
46162 - 46369 bearing
46162 - 46369 bearing
46162 - 46369 bearing
46162 - 46369 bearing
46162 - 46369 bearing
46162 - 46369 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

B:

31.75mm

C0r:

134N

D:

93.662mm

Category:

TaperedRollerBearings

Cr:

105N

Brand:

KOYOBearing

m:

1.098kg

d:

41.275mm

Model:

46162/46368

GreaseRPM:

44001/min

OilRPM:

58001/min

Cr:

104N

d:

41.275mm

C0r:

131N

Model:

4T-46162/46368

OilRPM:

55001/min

D:

93.662mm

Brand:

NTNBearing

GreaseRPM:

41001/min

NewModel:

4T-46162/46368

B:

31.75mm

Category:

TaperedRollerBearings

m:

1.09kg

Recommended models

11162 - 11315 26882 - 26820 3577 - 3530 3877 - 3821 439 - 432 24780 - 24721 25577 - 25519 49162 - 49368 464 - 453A 25577 - 25520 447 - 432X HM903244 - HM903210 3880 - 3821 3383 - 3328 HM803146 - HM803110 46162 - 46368 24781 - 24720 12168 - 12303 4395 - 4335 26882 - 26821 25578 - 25522 3880 - 3820 336 - 332US LM501349 - LM501314 59162 - 59429 HM803145 - HM803112 LM501349 - LM501310A LM300848 - LM300811 LM300849N - LM300811 26886 - 26820
