Timken 464A - 453A bearing

All our Timken 464A - 453A bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 464A - 453A

Series

455

Cone Part Number

464A

Cup Part Number

453A

Design Units

Imperial

Bearing Weight

3.1000 lb
1.4000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

4.2500 in
107.950 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.1542 in
29.317 mm

C - Cup Width

0.8750 in
22.225 mm

T - Bearing Width

1.0938 in
27.783 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.060 in
1.520 mm

r - Cup Backface "To Clear" Radius²

0.030 in
0.76 mm

da - Cone Frontface Backing Diameter

2.05 in
52.07 mm

db - Cone Backface Backing Diameter

2.13 in
54.10 mm

Da - Cup Frontface Backing Diameter

3.96 in
100.10 mm

Db - Cup Backface Backing Diameter

3.82 in
97.03 mm

Ab - Cage-Cone Frontface Clearance

0.05 in
1.27 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.28 in
-7.10 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

7900 lbf
35200 N

C1 - Dynamic Radial Rating (1 million revolutions)²

30500 lbf
136000 N

C0 - Static Radial Rating

37200 lbf
166000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

4540 lbf
20200 N

K - Factor¹

1.74

e - ISO Factor²

0.34

Y - ISO Factor³

1.79

G1 - Heat Generation Factor (Roller-Raceway)

58.6

G2 - Heat Generation Factor (Rib-Roller End)

17.1

Cg - Geometry Factor

0.0946

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 464A - 453A Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 464A - 453A Bearings, welcome to your calling.
