Timken 49162 - 49368 bearing

All our Timken 49162 - 49368 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 49162 - 49368

Series 49000
Cone Part Number 49162
Cup Part Number 49368
Design Units Imperial
Bearing Weight 2.3000 lb
1.0000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 3.6875 in
93.663 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 1.2500 in
31.750 mm
C - Cup Width 1.0000 in
25.400 mm
T - Bearing Width 1.2500 in
31.750 mm
Z - Number of Rollers Per Row 16
R - Cone Backface "To Clear" Radius1 0.140 in
3.560 mm
r - Cup Backface "To Clear" Radius2 0.130 in
3.30 mm
da - Cone Frontface Backing Diameter 1.97 in
50.04 mm
db - Cone Backface Backing Diameter 2.24 in
56.90 mm
Da - Cup Frontface Backing Diameter 3.46 in
87.88 mm
Db - Cup Backface Backing Diameter 3.23 in
82.04 mm
Ab - Cage-Cone Frontface Clearance 0.03 in
0.76 mm
Aa - Cage-Cone Backface Clearance 0.12 in
3.05 mm
a - Effective Center Location3 -0.36 in
-9.10 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 7900 lbf
35200 N
C1 - Dynamic Radial Rating (1 million revolutions)2 30500 lbf
136000 N
C0 - Static Radial Rating 35000 lbf
156000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 4870 lbf
21700 N
K - Factor1 1.62
e - ISO Factor2 0.36
Y - ISO Factor3 1.67
G1 - Heat Generation Factor (Roller-Raceway) 42.4
G2 - Heat Generation Factor (Rib-Roller End) 13.6
Cg - Geometry Factor 0.0872


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 49162 - 49368 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 49162 - 49368 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



Tapered Roller 49162 - 49368 Bearings_TS dimensions specifications Timken -Tancbearing

  • bearing 49162 - 49368 bearing
  • bearing 49162 - 49368 bearing
  • bearing 49162 - 49368 bearing
  • bearing 49162 - 49368 bearing
  • bearing 49162 - 49368 bearing
  • bearing 49162 - 49368 bearing
  • bearing 49162 - 49368 bearing
  • bearing 49162 - 49368 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 Brand:
TIMKENBearing
C0r:
156000N
B:
31.750mm
Cr:
126000N
D:
93.662mm
m:
1.03kg
Category:
TaperedRollerBearings
Model:
49162/49368
d:
41.275mm
