Timken 526 - 522 bearing

All our Timken 526 - 522 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 526 - 522

Series

525

Cone Part Number

526

Cup Part Number

522

Design Units

Imperial

Bearing Weight

3.1000 lb
1.4000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

4.0000 in
101.600 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.4200 in
36.068 mm

C - Cup Width

1.0625 in
26.988 mm

T - Bearing Width

1.3750 in
34.925 mm

Z - Number of Rollers Per Row

15

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

1.97 in
50.04 mm

db - Cone Backface Backing Diameter

2.24 in
56.90 mm

Da - Cup Frontface Backing Diameter

3.76 in
95.50 mm

Db - Cup Backface Backing Diameter

3.50 in
88.90 mm

Ab - Cage-Cone Frontface Clearance

0.07 in
1.78 mm

Aa - Cage-Cone Backface Clearance

0.11 in
2.79 mm

a - Effective Center Location³

-0.50 in
-12.70 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

9600 lbf
42700 N

C1 - Dynamic Radial Rating (1 million revolutions)²

37000 lbf
165000 N

C0 - Static Radial Rating

43000 lbf
191000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

4690 lbf
20800 N

K - Factor¹

2.05

e - ISO Factor²

0.29

Y - ISO Factor³

2.1

G1 - Heat Generation Factor (Roller-Raceway)

57.9

G2 - Heat Generation Factor (Rib-Roller End)

13.4

Cg - Geometry Factor

0.0894

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 526 - 522 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 526 - 522 Bearings, welcome to your calling.
