Timken 53162 - 53375 bearing

All our Timken 53162 - 53375 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 53162 - 53375

Series

53000

Cone Part Number

53162

Cup Part Number

53375

Design Units

Imperial

Bearing Weight

2.2000 lb
1.0000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.7500 in
95.250 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.1142 in
28.301 mm

C - Cup Width

0.8125 in
20.638 mm

T - Bearing Width

1.2188 in
30.958 mm

Z - Number of Rollers Per Row

14

R - Cone Backface "To Clear" Radius¹

0.060 in
1.520 mm

r - Cup Backface "To Clear" Radius²

0.030 in
0.76 mm

da - Cone Frontface Backing Diameter

2.07 in
52.58 mm

db - Cone Backface Backing Diameter

2.24 in
56.90 mm

Da - Cup Frontface Backing Diameter

3.54 in
89.90 mm

Db - Cup Backface Backing Diameter

3.19 in
81.03 mm

Ab - Cage-Cone Frontface Clearance

0.09 in
2.29 mm

Aa - Cage-Cone Backface Clearance

0.23 in
5.84 mm

a - Effective Center Location³

-0.01 in
-0.30 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

6920 lbf
30800 N

C1 - Dynamic Radial Rating (1 million revolutions)²

26700 lbf
119000 N

C0 - Static Radial Rating

23400 lbf
104000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

8760 lbf
39000 N

K - Factor¹

0.79

e - ISO Factor²

0.74

Y - ISO Factor³

0.81

G1 - Heat Generation Factor (Roller-Raceway)

26.7

G2 - Heat Generation Factor (Rib-Roller End)

9.63

Cg - Geometry Factor

0.093

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 53162 - 53375 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 53162 - 53375 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Timken Tapered Roller 53162 - 53375 Bearings_TS sale dimensions -Tancbearing

53162 - 53375 bearing
53162 - 53375 bearing
53162 - 53375 bearing
53162 - 53375 bearing
53162 - 53375 bearing
53162 - 53375 bearing
53162 - 53375 bearing
53162 - 53375 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Category:

TaperedRollerBearings

Model:

53162/53387

C0r:

104000N

d:

41.275mm

D:

98.425mm

m:

1.05kg

Cr:

92800N

Brand:

TIMKENBearing

B:

28.301mm

B:

44.450mm

d:

41.275mm

Category:

TaperedRollerBearings

Cr:

24000N

D:

95.250mm

m:

1.96kg

C0r:

30500N

Brand:

TIMKENBearing

Model:

53162/53376D

Brand:

NTNBearing

d:

41.275mm

Model:

4T-53162/53375

m:

0.975kg

B:

28.3mm

Cr:

82.5N

OilRPM:

50001/min

GreaseRPM:

37001/min

NewModel:

4T-53162/53375

D:

95.25mm

C0r:

92N

Category:

TaperedRollerBearings

m:

1.11kg

B:

28.301mm

Brand:

TIMKENBearing

Category:

TaperedRollerBearings

D:

98.425mm

Cr:

92800N

C0r:

104000N

d:

41.275mm

Model:

53162/53387-B

Model:

53162/53375

B:

28.301mm

C0r:

104000N

Category:

TaperedRollerBearings

d:

41.275mm

Brand:

TIMKENBearing

D:

95.250mm

Cr:

92800N

m:

0.98kg
