Timken 53162 - 53387 bearing

All our Timken 53162 - 53387 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 53162 - 53387

Series

53000

Cone Part Number

53162

Cup Part Number

53387

Design Units

Imperial

Bearing Weight

2.3000 lb
1.1000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.8750 in
98.425 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.1142 in
28.301 mm

C - Cup Width

0.8125 in
20.638 mm

T - Bearing Width

1.2188 in
30.958 mm

Z - Number of Rollers Per Row

14

R - Cone Backface "To Clear" Radius¹

0.060 in
1.520 mm

r - Cup Backface "To Clear" Radius²

0.030 in
0.76 mm

da - Cone Frontface Backing Diameter

2.07 in
52.58 mm

db - Cone Backface Backing Diameter

2.24 in
56.90 mm

Da - Cup Frontface Backing Diameter

3.62 in
91.90 mm

Db - Cup Backface Backing Diameter

3.23 in
82.04 mm

Ab - Cage-Cone Frontface Clearance

0.09 in
2.29 mm

Aa - Cage-Cone Backface Clearance

0.23 in
5.84 mm

a - Effective Center Location³

-0.01 in
-0.30 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

6920 lbf
30800 N

C1 - Dynamic Radial Rating (1 million revolutions)²

26700 lbf
119000 N

C0 - Static Radial Rating

23400 lbf
104000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

8760 lbf
39000 N

K - Factor¹

0.79

e - ISO Factor²

0.74

Y - ISO Factor³

0.81

G1 - Heat Generation Factor (Roller-Raceway)

26.7

G2 - Heat Generation Factor (Rib-Roller End)

9.63

Cg - Geometry Factor

0.093

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 53162 - 53387 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 53162 - 53387 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Timken SPEC Tapered Roller 53162 - 53387 Bearings_TS price -Tancbearing

53162 - 53387 bearing
53162 - 53387 bearing
53162 - 53387 bearing
53162 - 53387 bearing
53162 - 53387 bearing
53162 - 53387 bearing
53162 - 53387 bearing
53162 - 53387 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Brand:

NTNBearing

Cr:

82.5N

B:

28.3mm

D:

95.25mm

m:

0.975kg

Category:

TaperedRollerBearings

d:

41.275mm

OilRPM:

50001/min

NewModel:

4T-53162/53375

C0r:

92N

GreaseRPM:

37001/min

Model:

4T-53162/53375

B:

28.301mm

Brand:

TIMKENBearing

Cr:

92800N

m:

1.11kg

D:

98.425mm

C0r:

104000N

Model:

53162/53387-B

d:

41.275mm

Category:

TaperedRollerBearings

D:

95.250mm

d:

41.275mm

Model:

53162/53375

Cr:

92800N

Category:

TaperedRollerBearings

C0r:

104000N

Brand:

TIMKENBearing

B:

28.301mm

m:

0.98kg

Model:

53162/53376D

D:

95.250mm

B:

44.450mm

m:

1.96kg

Category:

TaperedRollerBearings

Brand:

TIMKENBearing

C0r:

30500N

d:

41.275mm

Cr:

24000N

Cr:

92800N

C0r:

104000N

Brand:

TIMKENBearing

D:

98.425mm

d:

41.275mm

Category:

TaperedRollerBearings

B:

28.301mm

m:

1.05kg

Model:

53162/53387

Recommended models

3579 - 3525 25578 - 25523 11165X - 11315 22168 - 22325 342-S - 332A 46162 - 46369 4395 - 4335 18590 - 18520 HM903245 - HM903210 24781 - 24720 342-S - 332 24780 - 24722 25577 - 25523 3383 - 3328 26884 - 26822 HM903244 - HM903210 LM501349 - LM501310A 25576 - 25521 365A - 362A 3383 - 3339 464A - 453A 26882 - 26820 4388 - 4328 65383 - 65320 336 - 332 53162 - 53375 3577 - 3525 526A - 522 336 - 333 LM501349A - LM501310
