Timken 541 - 532X bearing

All our Timken 541 - 532X bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 541 - 532X

Series

535

Cone Part Number

541

Cup Part Number

532X

Design Units

Imperial

Bearing Weight

3.8000 lb
1.7000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

4.2500 in
107.950 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.4550 in
36.957 mm

C - Cup Width

1.1250 in
28.575 mm

T - Bearing Width

1.4375 in
36.513 mm

Z - Number of Rollers Per Row

16

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.01 in
51.05 mm

db - Cone Backface Backing Diameter

2.28 in
57.91 mm

Da - Cup Frontface Backing Diameter

3.96 in
100.10 mm

Db - Cup Backface Backing Diameter

3.70 in
93.98 mm

Ab - Cage-Cone Frontface Clearance

0.04 in
1.02 mm

Aa - Cage-Cone Backface Clearance

0.11 in
2.79 mm

a - Effective Center Location³

-0.48 in
-12.20 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

10000 lbf
44600 N

C1 - Dynamic Radial Rating (1 million revolutions)²

38700 lbf
172000 N

C0 - Static Radial Rating

46200 lbf
206000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

5090 lbf
22700 N

K - Factor¹

1.97

e - ISO Factor²

0.3

Y - ISO Factor³

2.02

G1 - Heat Generation Factor (Roller-Raceway)

64.3

G2 - Heat Generation Factor (Rib-Roller End)

16.1

Cg - Geometry Factor

0.0938

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 541 - 532X Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 541 - 532X Bearings, welcome to your calling.
