Timken 59162 - 59412 bearing

All our Timken 59162 - 59412 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 59162 - 59412

Series

59000

Cone Part Number

59162

Cup Part Number

59412

Design Units

Imperial

Bearing Weight

3.5000 lb
1.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

4.1250 in
104.775 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.4375 in
36.513 mm

C - Cup Width

1.1250 in
28.575 mm

T - Bearing Width

1.4375 in
36.513 mm

Z - Number of Rollers Per Row

16

R - Cone Backface "To Clear" Radius¹

0.060 in
1.520 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.13 in
54.10 mm

db - Cone Backface Backing Diameter

2.20 in
55.88 mm

Da - Cup Frontface Backing Diameter

3.94 in
99.10 mm

Db - Cup Backface Backing Diameter

3.62 in
91.95 mm

Ab - Cage-Cone Frontface Clearance

0.05 in
1.27 mm

Aa - Cage-Cone Backface Clearance

0.14 in
3.56 mm

a - Effective Center Location³

-0.38 in
-9.70 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

11800 lbf
52400 N

C1 - Dynamic Radial Rating (1 million revolutions)²

45500 lbf
202000 N

C0 - Static Radial Rating

45400 lbf
202000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

8110 lbf
36100 N

K - Factor¹

1.45

e - ISO Factor²

0.4

Y - ISO Factor³

1.49

G1 - Heat Generation Factor (Roller-Raceway)

57.3

G2 - Heat Generation Factor (Rib-Roller End)

15.2

Cg - Geometry Factor

0.0999

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 59162 - 59412 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 59162 - 59412 Bearings, welcome to your calling.
