Timken 65383 - 65320 bearing

All our Timken 65383 - 65320 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 65383 - 65320

Series

65300

Cone Part Number

65383

Cup Part Number

65320

Design Units

Imperial

Bearing Weight

5.2000 lb
2.3000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

4.5000 in
114.300 mm

d - Cone Bore

1.6875 in
42.863 mm

B - Cone Width

1.7500 in
44.450 mm

C - Cup Width

1.3750 in
34.925 mm

T - Bearing Width

1.7500 in
44.450 mm

Z - Number of Rollers Per Row

14

R - Cone Backface "To Clear" Radius¹

0.080 in
2.030 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.36 in
59.94 mm

db - Cone Backface Backing Diameter

2.48 in
62.99 mm

Da - Cup Frontface Backing Diameter

4.25 in
107.95 mm

Db - Cup Backface Backing Diameter

3.82 in
97.03 mm

Ab - Cage-Cone Frontface Clearance

0.04 in
1.02 mm

Aa - Cage-Cone Backface Clearance

0.15 in
3.81 mm

a - Effective Center Location³

-0.49 in
-12.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

13000 lbf
58000 N

C1 - Dynamic Radial Rating (1 million revolutions)²

50300 lbf
224000 N

C0 - Static Radial Rating

57500 lbf
256000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

9600 lbf
42700 N

K - Factor¹

1.36

e - ISO Factor²

0.43

Y - ISO Factor³

1.39

G1 - Heat Generation Factor (Roller-Raceway)

63.1

G2 - Heat Generation Factor (Rib-Roller End)

13

Cg - Geometry Factor

0.105

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 65383 - 65320 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 65383 - 65320 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

specifications Timken Tapered Roller 65383 - 65320 Bearings_TS SPEC -Tancbearing

65383 - 65320 bearing
65383 - 65320 bearing
65383 - 65320 bearing
65383 - 65320 bearing
65383 - 65320 bearing
65383 - 65320 bearing
65383 - 65320 bearing
65383 - 65320 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Brand:

TIMKENBearing

Model:

65383/65320

d:

42.862mm

Category:

TaperedRollerBearings

B:

44.450mm

m:

2.35kg

D:

114.300mm

C0r:

256000N

Cr:

207000N
