Timken 25581 - 25520D bearing
All our Timken 25581 - 25520D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 25581 - 25520D
  |
| Bearing Weight | 2.8516 lb
1.2935 Kg
|
| D - Cup Outer Diameter | 3.2650 in
82.931 mm
|
| d - Cone Bore | 1.7500 in
44.450 mm
|
| B - Cone Width | 1.0000 in
25.400 mm
|
| C - Double Cup Width | 1.8750 in
47.625 mm
|
| T - Bearing Width across Cones | 2.2500 in
57.150 mm
|
| Z - Number of Rollers Per Row | 18
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.020 in
0.500 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 2.01 in
51.10 mm
|
| Da - Cup Frontface Backing Diameter | 3.05 in
77.47 mm
|
| Aa - Cage-Cone Backface Clearance | 0.04 in
1.00 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 5270 lbf
23500 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 35400 lbf
158000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 9180 lbf
40900 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 3020 lbf
13500 N
|
| Y1 - ISO Factor3 | 0.96
1.43
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 35.2
|
| G2 - Heat Generation Factor (Rib-Roller End) | 14.3
|
| Cg - Geometry Factor6 | 0.0801
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 25581 - 25520D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 25581 - 25520D Bearings, welcome to your calling.
