Timken 2578 - 2524YD bearing
All our Timken 2578 - 2524YD bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 2578 - 2524YD
  |
| Bearing Weight | 2.6284 lb
1.1922 Kg
|
| D - Cup Outer Diameter | 2.7500 in
69.850 mm
|
| d - Cone Bore | 1.1250 in
28.575 mm
|
| B - Cone Width | 0.9983 in
25.357 mm
|
| C - Double Cup Width | 2.2500 in
57.150 mm
|
| T - Bearing Width across Cones | 2.6250 in
66.675 mm
|
| Z - Number of Rollers Per Row | 16
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.090 in
2.300 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 1.54 in
39.10 mm
|
| Da - Cup Frontface Backing Diameter | 2.56 in
64.01 mm
|
| Aa - Cage-Cone Backface Clearance | 0.04 in
1.00 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 4880 lbf
21700 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 32800 lbf
146000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 8500 lbf
37800 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 2280 lbf
10200 N
|
| Y1 - ISO Factor3 | 1.19
1.78
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 23.6
|
| G2 - Heat Generation Factor (Rib-Roller End) | 9.63
|
| Cg - Geometry Factor6 | 0.0656
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 2578 - 2524YD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 2578 - 2524YD Bearings, welcome to your calling.
