Timken 2580 - 2524YD bearing
All our Timken 2580 - 2524YD bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 2580 - 2524YD
  |
| Bearing Weight | 2.5064 lb
1.1369 Kg
|
| D - Cup Outer Diameter | 2.7500 in
69.850 mm
|
| d - Cone Bore | 1.2500 in
31.750 mm
|
| B - Cone Width | 0.9983 in
25.357 mm
|
| C - Double Cup Width | 2.2500 in
57.150 mm
|
| T - Bearing Width across Cones | 2.6250 in
66.675 mm
|
| Z - Number of Rollers Per Row | 16
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.030 in
0.800 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 1.52 in
38.60 mm
|
| Da - Cup Frontface Backing Diameter | 2.56 in
64.01 mm
|
| Aa - Cage-Cone Backface Clearance | 0.04 in
1.00 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 4880 lbf
21700 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 32800 lbf
146000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 8500 lbf
37800 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 2280 lbf
10200 N
|
| Y1 - ISO Factor3 | 1.19
1.78
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 23.6
|
| G2 - Heat Generation Factor (Rib-Roller End) | 9.63
|
| Cg - Geometry Factor6 | 0.0656
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 2580 - 2524YD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 2580 - 2524YD Bearings, welcome to your calling.
FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF
please contact EMAIL :sales@tanchin.hk for any inquiry
dimensions Timken Tapered Roller 2580 - 2524YD Bearings_TS sale -Tancbearing
