Timken 2582 - 2524YD bearing

All our Timken 2582 - 2524YD bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 2582 - 2524YD

Series

2500

Cone Part Number

2582

Cup Part Number

2524YD

Design Units

Imperial

Bearing Weight

2.4964 lb
1.1323 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

2.7500 in
69.850 mm

d - Cone Bore

1.2500 in
31.750 mm

B - Cone Width

0.9983 in
25.357 mm

C - Double Cup Width

2.2500 in
57.150 mm

T - Bearing Width across Cones

2.6250 in
66.675 mm

Z - Number of Rollers Per Row

16

Ka - Locking Pin Diameter

N/A

Kb - Locking Pin Depth

N/A

R - Cone Backface "To Clear" Radius¹

0.140 in
3.600 mm

r - Cup Frontface "To Clear" Radius²

0.03 in
0.8 mm

db - Cone Backface Backing Diameter

1.73 in
43.90 mm

Da - Cup Frontface Backing Diameter

2.56 in
64.01 mm

Aa - Cage-Cone Backface Clearance

0.04 in
1.00 mm

C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)¹

4880 lbf
21700 N

C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)²

32800 lbf
146000 N

C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)³

8500 lbf
37800 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)⁴

2280 lbf
10200 N

K - Factor¹

2.14

e - ISO Factor²

0.57

Y1 - ISO Factor³

1.19
1.78

Y2 - ISO Factor⁴

1.78

G1 - Heat Generation Factor (Roller-Raceway)⁵

23.6

G2 - Heat Generation Factor (Rib-Roller End)

9.63

Cg - Geometry Factor⁶

0.0656

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 2582 - 2524YD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 2582 - 2524YD Bearings, welcome to your calling.
