Timken 26093 - 26284D bearing

All our Timken 26093 - 26284D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 26093 - 26284D

Series 26000
Cone Part Number 26093
Cup Part Number 26284D
Design Units Imperial
Bearing Weight 1.9826 lb
0.8993 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 2.8336 in
71.973 mm
d - Cone Bore 0.9375 in
23.813 mm
B - Cone Width 0.7450 in
18.923 mm
C - Double Cup Width 1.4375 in
36.513 mm
T - Bearing Width across Cones 1.6835 in
42.761 mm
Z - Number of Rollers Per Row 15
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.090 in
2.300 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 1.38 in
35.10 mm
Da - Cup Frontface Backing Diameter 2.60 in
65.02 mm
Aa - Cage-Cone Backface Clearance 0.02 in
0.50 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 3420 lbf
15200 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 23000 lbf
102000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 5960 lbf
26500 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 2110 lbf
9390 N
K - Factor1 1.62
e - ISO Factor2 0.76
Y1 - ISO Factor3 0.88
1.31
Y2 - ISO Factor4 1.31
G1 - Heat Generation Factor (Roller-Raceway)5 16.1
G2 - Heat Generation Factor (Rib-Roller End) 10.1
Cg - Geometry Factor6 0.063


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 26093 - 26284D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 26093 - 26284D Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



dimensions SPEC Tapered Roller 26093 - 26284D Bearings_TS Timken -Tancbearing

  • bearing 26093 - 26284D bearing
  • bearing 26093 - 26284D bearing
  • bearing 26093 - 26284D bearing
  • bearing 26093 - 26284D bearing
  • bearing 26093 - 26284D bearing
  • bearing 26093 - 26284D bearing
  • bearing 26093 - 26284D bearing
  • bearing 26093 - 26284D bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 d:
23.812mm
D:
72.000mm
B:
18.923mm
m:
0.44kg
Brand:
TIMKENBearing
Category:
TaperedRollerBearings
C0r:
60100N
Model:
26093/26283-B
Cr:
54400N
Brand:
TIMKENBearing
D:
71.438mm
m:
0.88kg
Cr:
14100N
Model:
26093/26282D
d:
23.812mm
B:
36.512mm
Category:
TaperedRollerBearings
C0r:
8700N
m:
0.9kg
Cr:
14100N
Category:
TaperedRollerBearings
d:
23.812mm
B:
36.512mm
D:
71.975mm
Brand:
TIMKENBearing
C0r:
8700N
Model:
26093/26284D
