Timken 26118 - 26282D bearing

All our Timken 26118 - 26282D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 26118 - 26282D

Series 26000
Cone Part Number 26118
Cup Part Number 26282D
Design Units Imperial
Bearing Weight 1.7786 lb
0.8068 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 2.8125 in
71.438 mm
d - Cone Bore 1.1806 in
29.987 mm
B - Cone Width 0.7450 in
18.923 mm
C - Double Cup Width 1.4375 in
36.513 mm
T - Bearing Width across Cones 1.6875 in
42.863 mm
Z - Number of Rollers Per Row 15
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.060 in
1.500 mm
r - Cup Frontface "To Clear" Radius2 0.02 in
0.4 mm
db - Cone Backface Backing Diameter 1.50 in
38.10 mm
Da - Cup Frontface Backing Diameter 2.60 in
65.02 mm
Aa - Cage-Cone Backface Clearance 0.02 in
0.50 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 4060 lbf
18100 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 27300 lbf
121000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 7070 lbf
31400 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 2500 lbf
11100 N
K - Factor1 1.62
e - ISO Factor2 0.76
Y1 - ISO Factor3 0.88
1.31
Y2 - ISO Factor4 1.31
G1 - Heat Generation Factor (Roller-Raceway)5 16.1
G2 - Heat Generation Factor (Rib-Roller End) 10.1
Cg - Geometry Factor6 0.063


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 26118 - 26282D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 26118 - 26282D Bearings, welcome to your calling.
