Timken 26118 - 26284D bearing
All our Timken 26118 - 26284D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 26118 - 26284D
  |
| Bearing Weight | 1.8166 lb
0.8240 Kg
|
| D - Cup Outer Diameter | 2.8336 in
71.973 mm
|
| d - Cone Bore | 1.1806 in
29.987 mm
|
| B - Cone Width | 0.7450 in
18.923 mm
|
| C - Double Cup Width | 1.4375 in
36.513 mm
|
| T - Bearing Width across Cones | 1.6835 in
42.761 mm
|
| Z - Number of Rollers Per Row | 15
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.060 in
1.500 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 1.50 in
38.10 mm
|
| Da - Cup Frontface Backing Diameter | 2.60 in
65.02 mm
|
| Aa - Cage-Cone Backface Clearance | 0.02 in
0.50 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 4060 lbf
18100 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 27300 lbf
121000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 7070 lbf
31400 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 2500 lbf
11100 N
|
| Y1 - ISO Factor3 | 0.88
1.31
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 16.1
|
| G2 - Heat Generation Factor (Rib-Roller End) | 10.1
|
| Cg - Geometry Factor6 | 0.063
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 26118 - 26284D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 26118 - 26284D Bearings, welcome to your calling.
