Timken 29680 - 29622D bearing
All our Timken 29680 - 29622D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 29680 - 29622D
  |
| Bearing Weight | 4.6768 lb
2.1214 Kg
|
| D - Cup Outer Diameter | 4.4995 in
114.287 mm
|
| d - Cone Bore | 2.7810 in
70.637 mm
|
| B - Cone Width | 1.0000 in
25.400 mm
|
| C - Double Cup Width | 1.8125 in
46.038 mm
|
| T - Bearing Width across Cones | 2.3124 in
58.735 mm
|
| Z - Number of Rollers Per Row | 27
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.050 in
1.300 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 3.15 in
80.00 mm
|
| Da - Cup Frontface Backing Diameter | 4.33 in
109.98 mm
|
| Aa - Cage-Cone Backface Clearance | 0.09 in
2.30 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 6440 lbf
28600 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 43300 lbf
192000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 11200 lbf
49900 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 5370 lbf
23900 N
|
| Y1 - ISO Factor3 | 0.62
0.92
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 77.7
|
| G2 - Heat Generation Factor (Rib-Roller End) | 43.3
|
| Cg - Geometry Factor6 | 0.117
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 29680 - 29622D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 29680 - 29622D Bearings, welcome to your calling.
