Timken 29685 - 29622D bearing

All our Timken 29685 - 29622D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 29685 - 29622D

Series 29600
Cone Part Number 29685
Cup Part Number 29622D
Design Units Imperial
Bearing Weight 4.4328 lb
2.0107 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 4.4995 in
114.287 mm
d - Cone Bore 2.8750 in
73.025 mm
B - Cone Width 1.0000 in
25.400 mm
C - Double Cup Width 1.8125 in
46.038 mm
T - Bearing Width across Cones 2.3124 in
58.735 mm
Z - Number of Rollers Per Row 27
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.140 in
3.600 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 3.39 in
86.10 mm
Da - Cup Frontface Backing Diameter 4.33 in
109.98 mm
Aa - Cage-Cone Backface Clearance 0.09 in
2.30 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 6440 lbf
28600 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 43300 lbf
192000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 11200 lbf
49900 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 5370 lbf
23900 N
K - Factor1 1.2
e - ISO Factor2 1.09
Y1 - ISO Factor3 0.62
0.92
Y2 - ISO Factor4 0.92
G1 - Heat Generation Factor (Roller-Raceway)5 77.7
G2 - Heat Generation Factor (Rib-Roller End) 43.3
Cg - Geometry Factor6 0.117


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 29685 - 29622D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 29685 - 29622D Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



SPEC Tapered Roller 29685 - 29622D Bearings_TS sale Timken -Tancbearing

  • bearing 29685 - 29622D bearing
  • bearing 29685 - 29622D bearing
  • bearing 29685 - 29622D bearing
  • bearing 29685 - 29622D bearing
  • bearing 29685 - 29622D bearing
  • bearing 29685 - 29622D bearing
  • bearing 29685 - 29622D bearing
  • bearing 29685 - 29622D bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 Brand:
TIMKENBearing
Model:
29685/29622DC/X1S-29685
Category:
TaperedRollerBearings
D:
114.287mm
C0r:
22100N
B:
46.038mm
d:
73.025mm
Cr:
26500N
m:
2.09kg
d:
73.025mm
C0r:
151N
Brand:
NTNBearing
OilRPM:
41001/min
NewModel:
4T-29685/29620
GreaseRPM:
31001/min
Category:
TaperedRollerBearings
m:
0.873kg
Cr:
95.5N
Model:
4T-29685/29620
D:
112.712mm
B:
25.4mm
GreaseRPM:
27001/min
Category:
TaperedRollerBearings
d:
73.025mm
B:
25.4mm
D:
112.713mm
C0r:
155000N
OilRPM:
38001/min
m:
0.871kg
Brand:
NACHIBearing
Model:
29685/29620
Cr:
97000N
D:
114.287mm
B:
46.038mm
C0r:
22100N
Category:
TaperedRollerBearings
Cr:
26500N
d:
73.025mm
Brand:
TIMKENBearing
m:
2.09kg
Model:
29685/29622D/X2S-29685
Model:
29685/29620
C0r:
155N
Cr:
97N
B:
25.4mm
Category:
TaperedRollerBearings
Brand:
KOYOBearing
D:
112.712mm
d:
73.025mm
GreaseRPM:
32001/min
OilRPM:
43001/min
m:
0.872kg
Brand:
TIMKENBearing
Category:
TaperedRollerBearings
B:
25.400mm
Cr:
102000N
D:
112.712mm
Model:
29685/29620
d:
73.025mm
C0r:
166000N
m:
0.89kg
