Timken 33251 - 33462D bearing

All our Timken 33251 - 33462D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 33251 - 33462D

Series 33000
Cone Part Number 33251
Cup Part Number 33462D
Design Units Imperial
Bearing Weight 6.8080 lb
3.0881 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 4.6250 in
117.475 mm
d - Cone Bore 2.5000 in
63.500 mm
B - Cone Width 1.1875 in
30.163 mm
C - Double Cup Width 2.1250 in
53.975 mm
T - Bearing Width across Cones 2.6249 in
66.672 mm
Z - Number of Rollers Per Row 23
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.030 in
0.800 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 2.87 in
72.90 mm
Da - Cup Frontface Backing Diameter 4.45 in
112.01 mm
Aa - Cage-Cone Backface Clearance 0.09 in
2.30 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 8060 lbf
35900 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 54200 lbf
241000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 14000 lbf
62400 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 6020 lbf
26800 N
K - Factor1 1.34
e - ISO Factor2 0.95
Y1 - ISO Factor3 0.71
1.06
Y2 - ISO Factor4 1.06
G1 - Heat Generation Factor (Roller-Raceway)5 84.2
G2 - Heat Generation Factor (Rib-Roller End) 25.9
Cg - Geometry Factor6 0.116


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 33251 - 33462D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 33251 - 33462D Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



dimensions Timken specifications Tapered Roller 33251 - 33462D Bearings_TS -Tancbearing

  • bearing 33251 - 33462D bearing
  • bearing 33251 - 33462D bearing
  • bearing 33251 - 33462D bearing
  • bearing 33251 - 33462D bearing
  • bearing 33251 - 33462D bearing
  • bearing 33251 - 33462D bearing
  • bearing 33251 - 33462D bearing
  • bearing 33251 - 33462D bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 Category:
TaperedRollerBearings
D:
117.475mm
C0r:
197000N
d:
63.500mm
Cr:
128000N
Brand:
TIMKENBearing
B:
30.162mm
Model:
33251/33462
m:
1.42kg
OilRPM:
40001/min
m:
1.54kg
d:
63.5mm
GreaseRPM:
30001/min
C0r:
168000N
Category:
TaperedRollerBearings
Cr:
112000N
D:
120mm
Model:
33251/33472
B:
30.162mm
Brand:
NACHIBearing
Model:
33251/33462D/X2S-33251
d:
63.500mm
Cr:
33200N
B:
53.975mm
Brand:
TIMKENBearing
Category:
TaperedRollerBearings
D:
117.475mm
m:
3.18kg
C0r:
24800N
