Timken 355A - 353D bearing
All our Timken 355A - 353D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 355A - 353D
  |
| Bearing Weight | 3.0276 lb
1.3733 Kg
|
| D - Cup Outer Diameter | 3.5480 in
90.119 mm
|
| d - Cone Bore | 1.7500 in
44.450 mm
|
| B - Cone Width | 0.8540 in
21.692 mm
|
| C - Double Cup Width | 1.7500 in
44.450 mm
|
| T - Bearing Width across Cones | 1.9998 in
50.795 mm
|
| Z - Number of Rollers Per Row | 16
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.030 in
0.800 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 2.01 in
51.10 mm
|
| Da - Cup Frontface Backing Diameter | 3.27 in
82.04 mm
|
| Aa - Cage-Cone Backface Clearance | 0.02 in
0.50 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 5650 lbf
25100 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 38000 lbf
169000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 9840 lbf
43800 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 2960 lbf
13200 N
|
| Y1 - ISO Factor3 | 1.06
1.57
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 30
|
| G2 - Heat Generation Factor (Rib-Roller End) | 12.2
|
| Cg - Geometry Factor6 | 0.0732
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 355A - 353D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 355A - 353D Bearings, welcome to your calling.
