Timken 365A - 363D bearing

All our Timken 365A - 363D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 365A - 363D

Series 365
Cone Part Number 365A
Cup Part Number 363D
Design Units Imperial
Bearing Weight 3.0504 lb
1.3836 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 3.5433 in
90.000 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 0.8750 in
22.225 mm
C - Double Cup Width 1.6563 in
42.070 mm
T - Bearing Width across Cones 1.9688 in
50.008 mm
Z - Number of Rollers Per Row 17
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.140 in
3.600 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 2.17 in
55.10 mm
Da - Cup Frontface Backing Diameter 3.34 in
84.84 mm
Aa - Cage-Cone Backface Clearance 0.02 in
0.50 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 5930 lbf
26400 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 39900 lbf
177000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 10300 lbf
46000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 3250 lbf
14400 N
K - Factor1 1.83
e - ISO Factor2 0.67
Y1 - ISO Factor3 1.01
1.50
Y2 - ISO Factor4 1.5
G1 - Heat Generation Factor (Roller-Raceway)5 33.8
G2 - Heat Generation Factor (Rib-Roller End) 14
Cg - Geometry Factor6 0.0773


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 365A - 363D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 365A - 363D Bearings, welcome to your calling.
