Timken 36690 - 36620D bearing

All our Timken 36690 - 36620D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 36690 - 36620D

Series 36600
Cone Part Number 36690
Cup Part Number 36620D
Design Units Imperial
Bearing Weight 10.5096 lb
4.7671 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 7.6250 in
193.675 mm
d - Cone Bore 5.7500 in
146.050 mm
B - Cone Width 1.1250 in
28.575 mm
C - Double Cup Width 2.1250 in
53.975 mm
T - Bearing Width across Cones 2.5623 in
65.082 mm
Z - Number of Rollers Per Row 43
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.060 in
1.500 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 6.10 in
154.90 mm
Da - Cup Frontface Backing Diameter 7.41 in
188.21 mm
Aa - Cage-Cone Backface Clearance 0.05 in
1.30 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 11400 lbf
50900 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 76900 lbf
342000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 19900 lbf
88600 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 7220 lbf
32100 N
K - Factor1 1.59
e - ISO Factor2 0.78
Y1 - ISO Factor3 0.86
1.28
Y2 - ISO Factor4 1.28
G1 - Heat Generation Factor (Roller-Raceway)5 366
G2 - Heat Generation Factor (Rib-Roller End) 121
Cg - Geometry Factor6 0.177


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 36690 - 36620D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 36690 - 36620D Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



Timken Tapered Roller 36690 - 36620D Bearings_TS dimensions SPEC -Tancbearing

  • bearing 36690 - 36620D bearing
  • bearing 36690 - 36620D bearing
  • bearing 36690 - 36620D bearing
  • bearing 36690 - 36620D bearing
  • bearing 36690 - 36620D bearing
  • bearing 36690 - 36620D bearing
  • bearing 36690 - 36620D bearing
  • bearing 36690 - 36620D bearing

please contact EMAIL :sales@tanchin.hk for any inquiry


Category:
TaperedRollerBearings
D:
203.200mm
C0r:
394000N
m:
2.8kg
Model:
36690/36626
B:
28.575mm
Cr:
182000N
Brand:
TIMKENBearing
d:
203.200mm
B:
53.975mm
D:
193.675mm
m:
4.94kg
C0r:
29700N
Model:
36690/36620DC/X1S-36690
d:
146.050mm
Cr:
47100N
Brand:
TIMKENBearing
Category:
TaperedRollerBearings
Category:
TaperedRollerBearings
C0r:
394000N
Brand:
TIMKENBearing
d:
146.050mm
B:
28.575mm
Model:
36690/36620-B
Cr:
182000N
m:
2.31kg
D:
193.675mm
B:
28.575mm
C0r:
375000N
D:
203.2mm
OilRPM:
22001/min
Model:
36690/36626
Cr:
181000N
GreaseRPM:
16001/min
d:
146.05mm
Category:
TaperedRollerBearings
m:
2.8kg
Brand:
NACHIBearing
m:
2.27kg
D:
193.675mm
Cr:
182000N
Category:
TaperedRollerBearings
B:
28.575mm
d:
193.675mm
Model:
36690/36620
Brand:
TIMKENBearing
C0r:
394000N
Model:
4T-36690/36620
Cr:
165N
d:
146.05mm
Brand:
NTNBearing
m:
2.27kg
B:
28.575mm
Category:
TaperedRollerBearings
C0r:
340N
NewModel:
4T-36690/36620
OilRPM:
22001/min
GreaseRPM:
16001/min
D:
193.675mm
