Timken 368A - 362XD bearing
All our Timken 368A - 362XD bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 368A - 362XD
  |
| Bearing Weight | 2.7264 lb
1.2367 Kg
|
| D - Cup Outer Diameter | 3.5427 in
89.985 mm
|
| d - Cone Bore | 2.0000 in
50.800 mm
|
| B - Cone Width | 0.8750 in
22.225 mm
|
| C - Double Cup Width | 1.9665 in
49.949 mm
|
| T - Bearing Width across Cones | 1.9842 in
50.399 mm
|
| Z - Number of Rollers Per Row | 17
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.140 in
3.600 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.02 in
0.5 mm
|
| db - Cone Backface Backing Diameter | 2.44 in
62.00 mm
|
| Da - Cup Frontface Backing Diameter | 3.41 in
86.61 mm
|
| Aa - Cage-Cone Backface Clearance | 0.02 in
0.50 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 5930 lbf
26400 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 39900 lbf
177000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 10300 lbf
46000 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 3250 lbf
14400 N
|
| Y1 - ISO Factor3 | 1.01
1.50
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 33.8
|
| G2 - Heat Generation Factor (Rib-Roller End) | 12.7
|
| Cg - Geometry Factor6 | 0.0773
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 368A - 362XD Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 368A - 362XD Bearings, welcome to your calling.
