Timken 370A - 363D bearing
All our Timken 370A - 363D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 370A - 363D
  |
| Bearing Weight | 2.4564 lb
1.1142 Kg
|
| D - Cup Outer Diameter | 3.5433 in
90.000 mm
|
| d - Cone Bore | 2.0000 in
50.800 mm
|
| B - Cone Width | 0.8750 in
22.225 mm
|
| C - Double Cup Width | 1.6563 in
42.070 mm
|
| T - Bearing Width across Cones | 1.9688 in
50.008 mm
|
| Z - Number of Rollers Per Row | 17
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.200 in
5.100 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 2.56 in
65.00 mm
|
| Da - Cup Frontface Backing Diameter | 3.34 in
84.84 mm
|
| Aa - Cage-Cone Backface Clearance | 0.02 in
0.50 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 5930 lbf
26400 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 39900 lbf
177000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 10300 lbf
46000 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 3250 lbf
14400 N
|
| Y1 - ISO Factor3 | 1.01
1.50
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 33.8
|
| G2 - Heat Generation Factor (Rib-Roller End) | 14
|
| Cg - Geometry Factor6 | 0.0773
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 370A - 363D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 370A - 363D Bearings, welcome to your calling.
FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF
please contact EMAIL :sales@tanchin.hk for any inquiry
dimensions Tapered Roller 370A - 363D Bearings_TS Timken sale -Tancbearing
