Timken 37431 - 37626D bearing

All our Timken 37431 - 37626D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 37431 - 37626D

Series 37000
Cone Part Number 37431
Cup Part Number 37626D
Design Units Imperial
Bearing Weight 6.5582 lb
2.9747 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 6.2500 in
158.750 mm
d - Cone Bore 4.3125 in
109.538 mm
B - Cone Width 0.8440 in
21.438 mm
C - Double Cup Width 1.5625 in
39.688 mm
T - Bearing Width across Cones 2.1251 in
53.978 mm
Z - Number of Rollers Per Row 32
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.140 in
3.600 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 4.84 in
122.90 mm
Da - Cup Frontface Backing Diameter 6.00 in
152.40 mm
Aa - Cage-Cone Backface Clearance 0.10 in
2.50 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 6710 lbf
29900 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 45100 lbf
201000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 11700 lbf
52000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 6960 lbf
31000 N
K - Factor1 0.96
e - ISO Factor2 1.45
Y1 - ISO Factor3 0.47
0.69
Y2 - ISO Factor4 0.69
G1 - Heat Generation Factor (Roller-Raceway)5 124
G2 - Heat Generation Factor (Rib-Roller End) 48.7
Cg - Geometry Factor6 0.144


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 37431 - 37626D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 37431 - 37626D Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



SPEC Tapered Roller 37431 - 37626D Bearings_TS Timken dimensions -Tancbearing

  • bearing 37431 - 37626D bearing
  • bearing 37431 - 37626D bearing
  • bearing 37431 - 37626D bearing
  • bearing 37431 - 37626D bearing
  • bearing 37431 - 37626D bearing
  • bearing 37431 - 37626D bearing
  • bearing 37431 - 37626D bearing
  • bearing 37431 - 37626D bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 m:
1.3kg
d:
158.750mm
Brand:
TIMKENBearing
Cr:
107000N
Model:
37431A/37625
Category:
TaperedRollerBearings
B:
21.438mm
D:
158.750mm
C0r:
179000N
d:
158.750mm
Model:
37431/37625
Cr:
107000N
Brand:
TIMKENBearing
B:
21.438mm
m:
1.31kg
C0r:
179000N
D:
158.750mm
Category:
TaperedRollerBearings
d:
109.538mm
Model:
37431/37625-B
D:
158.750mm
m:
1.38kg
Category:
TaperedRollerBearings
B:
21.438mm
Brand:
TIMKENBearing
Cr:
107000N
C0r:
179000N
C0r:
166N
OilRPM:
28001/min
NewModel:
4T-37431/37625
Cr:
102N
Model:
4T-37431/37625
D:
158.75mm
m:
1.33kg
GreaseRPM:
21001/min
Brand:
NTNBearing
B:
21.438mm
Category:
TaperedRollerBearings
d:
109.538mm
D:
158.75mm
m:
1.332kg
Category:
TaperedRollerBearings
C0r:
169N
d:
109.538mm
Model:
37431/37625
OilRPM:
30001/min
GreaseRPM:
22001/min
Brand:
KOYOBearing
B:
21.438mm
Cr:
104N
Brand:
TIMKENBearing
D:
158.750mm
m:
3.13kg
Model:
37431/37626D/X1S-37431
Category:
TaperedRollerBearings
d:
109.538mm
Cr:
27600N
C0r:
28700N
B:
39.688mm
Recommended models
370A - 363D   385X - 384D   42381 - 42587D   387A - 384D   3784 - 3729D   386A - 384ED   392 - 394D   386A - 384D   397 - 394DC   37431 - 37626DC   385A - 384D   357 - 353D   355X - 353D   389A - 384D   355X - 353DC   366 - 363DC   3775 - 3729D   368A - 362XD   385 - 384ED   34301 - 34478D   369-S - 363D   365A - 363D   EE420751 - 421451CD   350A - 353D   3476 - 3423D   3767 - 3729D   388A - 384ED   385A - 384EDC   36690 - 36620DC   359-S - 353D

please contact EMAIL :sales@tanchin.hk for any inquiry

Customer message

5. SKF BEARING 23068 CC/W33 QTYS : 2 PCS

Also, I consult the shipping company to determine the travel time by boat.

I found the information on the internet and I know your company offer INA bearings.

I would appreciate a quote for your lowest price brand.

is cognetex sfc22.

recheck your price offer.

N. 01 INA CSBE020.

We would like an official quote on the following order:

HCB7014E.T.P4S.UL FAG brand 10 PCS

Item: Taper Roller Bearing 1Unit Model: 74472/74851 CD with Spacer Beand: Timken (USA)

dimension of each item(s) and attach catalogue.

1) BEARING 23032 CC QTY: 2 PCS

I am Jessica working for Philips Healthcare Ultrasound Purchasing Organization in the US.

Cylindrical roller bearing （N NJ NU NUP series）

Delivery - 7 days PO Date
