Timken 37431 - 37626DC bearing
All our Timken 37431 - 37626DC bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 37431 - 37626DC
  |
| Bearing Weight | 6.5582 lb
2.9747 Kg
|
| D - Cup Outer Diameter | 6.2500 in
158.750 mm
|
| d - Cone Bore | 4.3125 in
109.538 mm
|
| B - Cone Width | 0.8440 in
21.438 mm
|
| C - Double Cup Width | 1.5625 in
39.688 mm
|
| T - Bearing Width across Cones | 2.1251 in
53.978 mm
|
| Z - Number of Rollers Per Row | 32
|
| Ka - Locking Pin Diameter | 0.5 in
12.7 mm
|
| Kb - Locking Pin Depth | 0.187 in
4.7 mm
|
| R - Cone Backface "To Clear" Radius1 | 0.140 in
3.600 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 4.84 in
122.90 mm
|
| Da - Cup Frontface Backing Diameter | 6.00 in
152.40 mm
|
| Aa - Cage-Cone Backface Clearance | 0.10 in
2.50 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 6710 lbf
29900 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 45100 lbf
201000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 11700 lbf
52000 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 6960 lbf
31000 N
|
| Y1 - ISO Factor3 | 0.47
0.69
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 124
|
| G2 - Heat Generation Factor (Rib-Roller End) | 48.7
|
| Cg - Geometry Factor6 | 0.144
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 37431 - 37626DC Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 37431 - 37626DC Bearings, welcome to your calling.
