Timken 376X - 372D bearing
All our Timken 376X - 372D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 376X - 372D
  |
| Bearing Weight | 3.8750 lb
1.7577 Kg
|
| D - Cup Outer Diameter | 3.9370 in
100.000 mm
|
| d - Cone Bore | 1.7717 in
45.001 mm
|
| B - Cone Width | 0.8750 in
22.225 mm
|
| C - Double Cup Width | 1.5626 in
39.690 mm
|
| T - Bearing Width across Cones | 1.9999 in
50.797 mm
|
| Z - Number of Rollers Per Row | 18
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.080 in
2.000 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 2.20 in
55.90 mm
|
| Da - Cup Frontface Backing Diameter | 3.56 in
89.92 mm
|
| Aa - Cage-Cone Backface Clearance | 0.03 in
0.80 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 4750 lbf
21100 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 31900 lbf
142000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 8260 lbf
36800 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 2750 lbf
12200 N
|
| Y1 - ISO Factor3 | 0.95
1.41
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 37.6
|
| G2 - Heat Generation Factor (Rib-Roller End) | 15.4
|
| Cg - Geometry Factor6 | 0.0816
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 376X - 372D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 376X - 372D Bearings, welcome to your calling.
