Timken 3784 - 3729D bearing
All our Timken 3784 - 3729D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 3784 - 3729D
  |
| Bearing Weight | 3.8702 lb
1.7555 Kg
|
| D - Cup Outer Diameter | 3.6718 in
93.264 mm
|
| d - Cone Bore | 2.0000 in
50.800 mm
|
| B - Cone Width | 1.1930 in
30.302 mm
|
| C - Double Cup Width | 2.0625 in
52.388 mm
|
| T - Bearing Width across Cones | 2.5625 in
65.088 mm
|
| Z - Number of Rollers Per Row | 18
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.250 in
6.400 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 2.76 in
70.10 mm
|
| Da - Cup Frontface Backing Diameter | 3.50 in
88.90 mm
|
| Aa - Cage-Cone Backface Clearance | 0.07 in
1.80 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 7120 lbf
31700 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 47800 lbf
213000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 12400 lbf
55100 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 4120 lbf
18300 N
|
| Y1 - ISO Factor3 | 0.95
1.41
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 49.9
|
| G2 - Heat Generation Factor (Rib-Roller End) | 14.5
|
| Cg - Geometry Factor6 | 0.0903
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 3784 - 3729D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 3784 - 3729D Bearings, welcome to your calling.
