Timken 387A - 384ED bearing
All our Timken 387A - 384ED bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 387A - 384ED
  |
| Bearing Weight | 3.0996 lb
1.4060 Kg
|
| D - Cup Outer Diameter | 3.9370 in
100.000 mm
|
| d - Cone Bore | 2.2500 in
57.150 mm
|
| B - Cone Width | 0.8640 in
21.946 mm
|
| C - Double Cup Width | 1.5620 in
39.675 mm
|
| T - Bearing Width across Cones | 1.9369 in
49.197 mm
|
| Z - Number of Rollers Per Row | 19
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.140 in
3.600 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 2.76 in
70.10 mm
|
| Da - Cup Frontface Backing Diameter | 3.68 in
93.47 mm
|
| Aa - Cage-Cone Backface Clearance | 0.04 in
1.00 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 6280 lbf
28000 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 42200 lbf
188000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 10900 lbf
48700 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 3810 lbf
16900 N
|
| Y1 - ISO Factor3 | 0.90
1.34
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 42
|
| G2 - Heat Generation Factor (Rib-Roller End) | 15.7
|
| Cg - Geometry Factor6 | 0.0859
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 387A - 384ED Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 387A - 384ED Bearings, welcome to your calling.
