Timken 387A - 384EDC bearing

All our Timken 387A - 384EDC bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 387A - 384EDC

Series 385
Cone Part Number 387A
Cup Part Number 384EDC
Design Units Imperial
Bearing Weight 3.0996 lb
1.4060 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 3.9370 in
100.000 mm
d - Cone Bore 2.2500 in
57.150 mm
B - Cone Width 0.8640 in
21.946 mm
C - Double Cup Width 1.5620 in
39.675 mm
T - Bearing Width across Cones 1.9369 in
49.197 mm
Z - Number of Rollers Per Row 19
Ka - Locking Pin Diameter 0.5 in
12.7 mm
Kb - Locking Pin Depth 0.156 in
4 mm
R - Cone Backface "To Clear" Radius1 0.140 in
3.600 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 2.76 in
70.10 mm
Da - Cup Frontface Backing Diameter 3.68 in
93.47 mm
Aa - Cage-Cone Backface Clearance 0.04 in
1.00 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 6280 lbf
28000 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 42200 lbf
188000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 10900 lbf
48700 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 3810 lbf
16900 N
K - Factor1 1.65
e - ISO Factor2 0.75
Y1 - ISO Factor3 0.90
1.34
Y2 - ISO Factor4 1.34
G1 - Heat Generation Factor (Roller-Raceway)5 42
G2 - Heat Generation Factor (Rib-Roller End) 15.7
Cg - Geometry Factor6 0.0859


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 387A - 384EDC Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 387A - 384EDC Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



Timken SPEC Tapered Roller 387A - 384EDC Bearings_TS dimensions -Tancbearing

  • bearing 387A - 384EDC bearing
  • bearing 387A - 384EDC bearing
  • bearing 387A - 384EDC bearing
  • bearing 387A - 384EDC bearing
  • bearing 387A - 384EDC bearing
  • bearing 387A - 384EDC bearing
  • bearing 387A - 384EDC bearing
  • bearing 387A - 384EDC bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 Model:
387/382A
C0r:
101N
GreaseRPM:
39001/min
m:
0.605kg
B:
21.946mm
d:
57.15mm
D:
96.838mm
Category:
TaperedRollerBearings
OilRPM:
52001/min
Cr:
80.4N
Brand:
KOYOBearing
C0r:
343000N
Cr:
207000N
D:
161.925mm
Brand:
TIMKENBearing
m:
2.76kg
Category:
TaperedRollerBearings
B:
36.116mm
d:
161.925mm
Model:
52387/52637
d:
57.15mm
Model:
387A/382A
Category:
TaperedRollerBearings
B:
21.946mm
Brand:
NACHIBearing
m:
0.604kg
Cr:
80400N
D:
96.838mm
OilRPM:
59001/min
C0r:
101000N
GreaseRPM:
42001/min
Model:
4T-387S/382A
OilRPM:
50001/min
C0r:
96.5N
Cr:
78N
Brand:
NTNBearing
NewModel:
4T-387S/382A
Category:
TaperedRollerBearings
d:
57.15mm
GreaseRPM:
37001/min
m:
0.585kg
D:
96.838mm
B:
21.946mm
m:
0.89kg
B:
30.162mm
d:
36.512mm
OilRPM:
64001/min
Cr:
108N
Model:
3878/3820
GreaseRPM:
48001/min
Brand:
KOYOBearing
D:
85.725mm
C0r:
136N
Category:
TaperedRollerBearings
Category:
TaperedRollerBearings
m:
0.651kg
Cr:
80.4N
B:
21.946mm
GreaseRPM:
39001/min
OilRPM:
52001/min
d:
57.15mm
Brand:
KOYOBearing
C0r:
101N
Model:
387/382
D:
98.425mm
Recommended models
43125 - 43319D   387AS - 384D   36690 - 36620DC   42381 - 42587D   387AS - 384ED   36690 - 36620D   436 - 432D   385A - 384EDC   395-S - 394D   385A - 384ED   44158 - 44363D   365A - 363D   43131 - 43319D   397 - 394D   3782 - 3729D   385X - 384D   447 - 432D   389A - 384D   440 - 432D   388A - 384D   EE435102 - 435165D   365-S - 363D   385 - 384D   390A - 394D   395 - 394D   EE430902 - 431576CD   376X - 372D   43132 - 43319D   366 - 363D   395-S - 394DC
