Timken 387-S - 384DC bearing
All our Timken 387-S - 384DC bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 387-S - 384DC
  |
| Bearing Weight | 3.3146 lb
1.5035 Kg
|
| D - Cup Outer Diameter | 3.9370 in
100.000 mm
|
| d - Cone Bore | 2.2500 in
57.150 mm
|
| B - Cone Width | 0.8640 in
21.946 mm
|
| C - Double Cup Width | 1.6875 in
42.863 mm
|
| T - Bearing Width across Cones | 2.0624 in
52.385 mm
|
| Z - Number of Rollers Per Row | 19
|
| Ka - Locking Pin Diameter | 0.5 in
12.7 mm
|
| Kb - Locking Pin Depth | 0.156 in
4 mm
|
| R - Cone Backface "To Clear" Radius1 | 0.030 in
0.800 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 2.52 in
64.00 mm
|
| Da - Cup Frontface Backing Diameter | 3.68 in
93.47 mm
|
| Aa - Cage-Cone Backface Clearance | 0.04 in
1.00 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 6280 lbf
28000 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 42200 lbf
188000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 10900 lbf
48700 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 3810 lbf
16900 N
|
| Y1 - ISO Factor3 | 0.90
1.34
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 42
|
| G2 - Heat Generation Factor (Rib-Roller End) | 15.7
|
| Cg - Geometry Factor6 | 0.0859
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 387-S - 384DC Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 387-S - 384DC Bearings, welcome to your calling.
