Timken 392 - 394D bearing

All our Timken 392 - 394D bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 392 - 394D

Series 395
Cone Part Number 392
Cup Part Number 394D
Design Units Imperial
Bearing Weight 4.1248 lb
1.8710 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 4.3307 in
110.000 mm
d - Cone Bore 2.4375 in
61.913 mm
B - Cone Width 0.8660 in
21.996 mm
C - Double Cup Width 1.8125 in
46.038 mm
T - Bearing Width across Cones 2.0624 in
52.385 mm
Z - Number of Rollers Per Row 22
Ka - Locking Pin Diameter N/A
Kb - Locking Pin Depth N/A
R - Cone Backface "To Clear" Radius1 0.030 in
0.800 mm
r - Cup Frontface "To Clear" Radius2 0.03 in
0.8 mm
db - Cone Backface Backing Diameter 2.76 in
70.10 mm
Da - Cup Frontface Backing Diameter 4.12 in
104.65 mm
Aa - Cage-Cone Backface Clearance 0.07 in
1.80 mm
C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 5760 lbf
25600 N
C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 38700 lbf
172000 N
C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 10000 lbf
44600 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)4 3970 lbf
17600 N
K - Factor1 1.45
e - ISO Factor2 0.87
Y1 - ISO Factor3 0.78
1.16
Y2 - ISO Factor4 1.16
G1 - Heat Generation Factor (Roller-Raceway)5 56
G2 - Heat Generation Factor (Rib-Roller End) 21.4
Cg - Geometry Factor6 0.0984


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 392 - 394D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 392 - 394D Bearings, welcome to your calling.
