Timken 399AS - 394DC bearing
All our Timken 399AS - 394DC bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 399AS - 394DC
  |
| Bearing Weight | 3.5348 lb
1.6034 Kg
|
| D - Cup Outer Diameter | 4.3307 in
110.000 mm
|
| d - Cone Bore | 2.6875 in
68.263 mm
|
| B - Cone Width | 0.8660 in
21.996 mm
|
| C - Double Cup Width | 1.8125 in
46.038 mm
|
| T - Bearing Width across Cones | 2.0624 in
52.385 mm
|
| Z - Number of Rollers Per Row | 22
|
| Ka - Locking Pin Diameter | 0.562 in
14.3 mm
|
| Kb - Locking Pin Depth | 0.125 in
3.2 mm
|
| R - Cone Backface "To Clear" Radius1 | 0.200 in
5.100 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 3.27 in
83.10 mm
|
| Da - Cup Frontface Backing Diameter | 4.12 in
104.65 mm
|
| Aa - Cage-Cone Backface Clearance | 0.07 in
1.80 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 5760 lbf
25600 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 38700 lbf
172000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 10000 lbf
44600 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 3970 lbf
17600 N
|
| Y1 - ISO Factor3 | 0.78
1.16
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 56
|
| G2 - Heat Generation Factor (Rib-Roller End) | 21.4
|
| Cg - Geometry Factor6 | 0.0984
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 399AS - 394DC Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 399AS - 394DC Bearings, welcome to your calling.
