Timken 42346 - 42587D bearing
All our Timken 42346 - 42587D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 42346 - 42587D
  |
| Bearing Weight | 9.4230 lb
4.2742 Kg
|
| D - Cup Outer Diameter | 5.8750 in
149.225 mm
|
| d - Cone Bore | 3.4630 in
87.960 mm
|
| B - Cone Width | 1.1406 in
28.971 mm
|
| C - Double Cup Width | 2.0625 in
52.388 mm
|
| T - Bearing Width across Cones | 2.6248 in
66.670 mm
|
| Z - Number of Rollers Per Row | 26
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.120 in
3.000 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.03 in
0.8 mm
|
| db - Cone Backface Backing Diameter | 4.06 in
103.10 mm
|
| Da - Cup Frontface Backing Diameter | 5.64 in
143.26 mm
|
| Aa - Cage-Cone Backface Clearance | 0.11 in
2.80 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 11300 lbf
50100 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 75600 lbf
336000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 19600 lbf
87100 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 9480 lbf
42200 N
|
| Y1 - ISO Factor3 | 0.61
0.91
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 130
|
| G2 - Heat Generation Factor (Rib-Roller End) | 37.2
|
| Cg - Geometry Factor6 | 0.139
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 42346 - 42587D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 42346 - 42587D Bearings, welcome to your calling.
