Timken 43117 - 43319D bearing
All our Timken 43117 - 43319D bearings ensure quality
Price :$1.08,please contact sales@tanchin.hk Timken 43117 - 43319D
  |
| Bearing Weight | 2.8844 lb
1.3083 Kg
|
| D - Cup Outer Diameter | 3.1875 in
80.963 mm
|
| d - Cone Bore | 1.1806 in
29.987 mm
|
| B - Cone Width | 0.9478 in
24.074 mm
|
| C - Double Cup Width | 1.5625 in
39.688 mm
|
| T - Bearing Width across Cones | 2.1875 in
55.563 mm
|
| Z - Number of Rollers Per Row | 13
|
| Ka - Locking Pin Diameter | N/A
|
| Kb - Locking Pin Depth | N/A
|
| R - Cone Backface "To Clear" Radius1 | 0.060 in
1.500 mm
|
| r - Cup Frontface "To Clear" Radius2 | 0.06 in
1.5 mm
|
| db - Cone Backface Backing Diameter | 1.75 in
44.50 mm
|
| Da - Cup Frontface Backing Diameter | 2.94 in
73.91 mm
|
| Aa - Cage-Cone Backface Clearance | 0.13 in
3.30 mm
|
| C90 - Dynamic Radial Rating (One-Row, 90 million revolutions)1 | 4520 lbf
20100 N
|
| C1 - Dynamic Radial Rating (Two-Row, 1 million revolutions)2 | 30400 lbf
135000 N
|
| C90(2) - Dynamic Radial Rating (Two-Row, 90 million revolutions)3 | 7880 lbf
35000 N
|
| Ca90 - Dynamic Thrust Rating (90 million revolutions)4 | 5170 lbf
23000 N
|
| Y1 - ISO Factor3 | 0.41
0.60
|
| G1 - Heat Generation Factor (Roller-Raceway)5 | 16.8
|
| G2 - Heat Generation Factor (Rib-Roller End) | 7.57
|
| Cg - Geometry Factor6 | 0.0774
|
|
In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 43117 - 43319D Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 43117 - 43319D Bearings, welcome to your calling.
